Mooer Ocean Machine II Delay & Reverb Pedal (TLD4)

---

Similarly to the original, the Ocean Machine II offers two independent delay modules, each with nine different delay types of up to two seconds, including household names such as digital, tape, and echo delays, as well as more abstract options, such as galaxy, crystal, and rainbow. A high-fidelity reverb module complements these delays with nine reverb types, as well as a shimmer effect. Each delay and reverb effect can also be ‘frozen,’ creating static ambient drones, an effect that sounds particularly impressive considering the pedal’s DSP upgrades. While the original Ocean Machine’s looping capabilities provided just 44 seconds of loop storage, the new addition features an impressive 120 seconds. To experiment with this feature, along with Ocean Machine II’s other sonic capabilities, users can use an intuitive LCD screen along with 12 knobs (four for each delay and reverb module) to easily adjust parameters within the device’s ‘Play Mode.’ Three footswitches are also provided to facilitate independent effect toggling, tap tempo control, looper interfacing, and a preset selector.

---

FEATURES

• Improved DSP algorithms for superior delay and reverb quality
• Nine distinct delay types that support up to 2 seconds of delay time: digital, analog, tape, echo, liquid, rainbow, crystal, low-bit, and fuzzy delays
• Nine hi-fidelity reverb types: room, hall, plate, distorted reverb, flanger reverb, filter reverb, reverse, spring, and modulated reverb
• Freeze feedback feature, supported for both delay and reverb effects
• Tap tempo footswitch functionality
• New and improved looper supporting up to 120 seconds of recording time, along with overdubbing capabilities, half-speed, and reverse effects.
• Customizable order of effects in parallel or series chains
• Flexible bypass options supporting both true bypass and DSP bypass
• Large LCD screen, controllable through twelve easy-to-use physical knobs for real-time parameter adjustments.
• Adjustable Global EQ Settings
• Full stereo inputs and outputs
• Synchronizable and mappable MIDI In and Thru support
• USB-C port for firmware updates
• External expression pedal support via TRS cable
• Support for the MOOER F4 wireless footswitch (sold separately)
• Designed for durability and reliability in both studio and live environments.

---

SPECIFICATIONS

• Dimensions: 215 x 127 x 56 mm
• Weight: 1.1 kg
• Power Supply: 9V DC
• Sampling Rate: 44.1 kHz
• Sampling Accuracy: 24-bit

---
