Medeli AK603 61-Key Keyboard (AK-603)

---

AK603 is a brand new standard in the middle-class keyboard segment, bringing all performance and musical experiences from our flagship model. From its rich cabinet and speakers, down to the modern sound and effect engines, AK603 is just as powerful a workhorse that provides you all practical features and specifications. The main piano sound is our exclusive German Grand, the new keyboard is highly expressive and stable, the GrandSuite editing software effectively expands and manages this keyboard, and the new Phrase Pad and Break features provide fresh and alternative flavours to your performance.

---

SPECIFICATIONS

• Keyboard 61 Keys (Touch-sensitive)
• Touch Response 5 Levels (Soft1, 2 / Normal / Hard1, 2)
• Display Backlit LCD
• 4.5" x 2.4"
• Language English
• Polyphony 256
• Sound 750 Preset
• 50 User
• Synth mode to edit on-board PCM data
• Keyboard Part L, R1, R2
• Effect 32 x Reverb types
• 64 x Chorus types
• 24 x Insert Effect types
• 5 x Preset EQ types and 7 band controls
• D.A.S. (Loudness-compensated Volume, fixed)
• Part Effect 13 x Harmony types
• 4 x Echo types
• 4 x Tremolo types
• 4 x Trill types
• 6 x Arpeggio types
• Chord 39 Chord types
• 4 x Chord Detection modes (Fingered, Multi Fingered, Bass Invert, Smart Full Range)
• Chord Reference
• Style 280 Preset
• 50 User
• Style Control Start / Stop
• Sync Start / Sync Stop
• Intro 1 / Ending 1
• Intro 2 / Ending 2
• Intro 3 / Ending 3
• Main A / Fill in A
• Main B / Fill in B
• Main C / Fill in C
• Main D / Fill in D
• Break
• Auto Fill in
• Chord Mode
• Fade in / out
• Quick Setting 4 for each Style
• Song 90 Preset
• Song Control Song Select
• Start/Stop
• Pause
• Loop Playback (Single song / All songs)
• FF
• RW
• Song Recording 5 User
• 16 Tracks
• Maximum 20,000 MIDI notes per song
• Album 50 Preset
• Audio Recording WAV (44.1KHz / 16bit)
• MP3 (320 kbps)
• Audio Playback WAV
• MP3
• Demo Song 3
• Phrase Pad 4 x 100 Banks
• Tempo 5 ~ 320 BPM
• Scale Setting Transpose (-12 ~ +12)
• Octave (-2 ~ +2)
• Tuning (-50 ~ +50 cents)
• Performance Memory 6 x 32 Banks
• Parameter Lock function
• Controller 1 x Sustain Pedal (Assignable)
• 1 x Expression Pedal (Assignable)
• 1 x Joystick (Pitchbend, Modulation and an assignable parameter)
• Mixer 17 Parts
• Other Controller Volume knob, Data dial with Enter button, < / > buttons, Exit button, Tempo < / >,
• Metronome, Tap Tempo buttons, Mixer, Function, USB access, Demo buttons, Transpose < / >, Octave < / > buttons, IFX, Arpeggio, Harmony buttons, Touch sens, Sustain button, Sound and Style direction selection buttons, Sound part on / off buttons,
• Q.S. 1 ~ 4 buttons
• USB Storage Device Playback: Song (MID / WAV / MP3), Style
• Saving: Song, Device Information
• Loading: Song (MID), Expansion Style
• Maximum 256GB storage device handling
• Connectivity 1 x 1/4" Stereo Headphones Output
• 1 x 1/4" Stereo AUX Input
• 2 x 1/4" Line Output (L/Mono, R)
• 1 x 1/4" Sustain Pedal Input (Assignable)
• 1 x 1/4" Expression Pedal Input (Assignable)
• 1 x USB-B (MIDI & Audio)
• 1 x USB-A (Device)
• Other Setting Tuning, Metronome Time Signature, Fade In/Out Time, Split Point, Harmony Type,
• Arpeggio Type, Arpeggio Hold on/off, Lock (Parameters), Sustain Pedal Assignment,
• Expression Pedal Assignment, Joystick Assignment (Down), Recorder Mode, MIDI
• Out channel, Auto Power Off, Factory Reset
• Expansion Data PC software kit which can edit user data
• Software & App GrandSuite
• Power DC15V
• Amplifier Woofer: 2 x 25W
• Tweeter: 2 x 15W
• Speakers 2 x 12 cm
• 2 x 3 cm
• Dimensions 971 (W) x 390 (D) x 130 (H) mm

---
