JTS CS-120CU Control Unit for Conference System

---

CS-120CU works as a main unit of the whole system. It provides all inputs and outputs needed to manage complex audio system. A single CS-120CU can be connected with 90 sets of CS-120CH and CS-120DU. With additional power unit CS-120EMU up to 256 sets can be connected. It meets most conference requirement. Voting function is also provided. Large LCD screen provides detailed information.

---

FEATURES

• It meets most conference requirement.
• Voting function is also provided.
• Large LCD screen provides detailed information.
• Soft-key design provides intuitive operation.
• Maximum 4 video cameras can be connected to perform video tracking.

---

SPECIFICATIONS

• Supply voltage : AC110Vor AC220V (default settings)
• Number of connectable conference units : ≤254
• Frequency response : 40-16000Hz
• Signal-to-noise ratio : >80dBA
• Dynamic range : >85dB
• Audio crosstalk : >70dB
• Total harmonic distortion : <0.05% | Original input: 6.3 mm balanced | Signal strength: 0.775 V
• Audio inputs : Recording input: RCA type*1 | Original output: RCA*2 balanced, XLR*1 balanced
• Audio outputs : Recording output: RCA type*1
• SD card slot : Support 32GB SD card in FAT format
• LAN interface : RJ45 , or PC control
• Conference unit connector : DIN7P
• Maximum power consumption : 200W

---
