DPA 4099 CORE Instrument Microphone Stereo Kit with Accordion Holders (4099A)

---

This mic solution makes it easy to achieve a high level of isolation on stage. It also provides clean and transparent stereo sound quality with realistic dynamics. It is a complete system, which includes a pair of 4099 CORE for Loud SPL selected on sensitivity within ±1.5 dB. The two included mic clips can be attached permanently to the instrument using screws.

---

FEATURES

• CORE by DPA technology inside
• Supercardioid condenser microphone
• Handles high SPLs
• Superior gain-before-feedback
• Flexible and easy mounting
• Gentle and easy to mount on the instrument
• Detachable cable and a versatile gooseneck extender

---

SPECIFICATIONS

• Directional characteristics : Supercardioid
• Principle of operation : Pressure gradient
• Cartridge type : Pre-polarized condenser
• Frequency range : 20 Hz to 20 kHz
• Frequency range, ± 2 dB, 20 cm (7.9 in) distance : 80 Hz to 15 kHz with 2 dB soft boost at 10 to 12 kHz
• Sensitivity, nominal ± 3 dB at 1 kHz : 6 mV/Pa; -44,5 dB re. 1 V/Pa (High SPL: 2 mV/Pa; -54 dB re. 1 V/Pa)
• Equivalent noise level, A-weighted : Typ. 23 dB(A) re. 20 μPa (max. 26 dB(A)) (d:vote High SPL: Typ. 28 dB(A) re. 20 μPa (max. 31 dB(A))
• S/N ratio (A-weighted), re. 1 kHz at 1 Pa (94 dB SPL) : 71 dB (High SPL: 66 dB(A))
• Total Harmonic Distortion (THD) : <1 % up to 123 dB SPL peak; <1 % up to 120 dB SPL RMS sine (High SPL: <1 % up to 123 dB SPL peak; <1 % up to 120 dB SPL RMS sine)
• Dynamic range : 100 dB (High SPL: 95 dB)
• Max. SPL, peak before clipping : 142 dB (High SPL: 152 dB
• Output impedance : From MicroDot: 30 to 40 ohm; from XLR adapter: 100 ohm
• Cable drive capability : Up to 300 m (984 ft) with XLR adapter
• Output balance principle : Signal balanced with XLR adapter
• Common Mode Rejection Ratio (CMRR) : > 60 dB from 50 Hz to 15 kHz with XLR adapter
• Power supply (for full performance) : Min. 5 V to max. 50 V through DPA adapter for wireless systems, 48 V phantom power +/- 4 V with XLR adapter
• Current consumption : Typ. 1.5 mA (microphone). 3.5 mA with XLR adapter
• Connector : MicroDot
• Color : Black
• Dimensions : Microphone weight: 46 g (1.62 oz) Capsule diameter: 5.4 mm (0.2 in) Microphone length: 45 mm (1.8 in) Cable length: 1.8 m (6 ft)
• Polarity : Positively increasing sound pressure produces positive-going voltage at MicroDot pin (and pin 2 on XLR adapter)
• Temperature range : -40 °C to 45 °C (-40 °F to 113 °F)
• Relative Humidity (RH) : Up to 90%
• Gooseneck length : 140 mm (5.5 in)
• Sensitivity selection tolerance (at 1 kHz) : ± 1 dB

---
