Bose Panaray MA12 Modular Vertical Line-Array Loudspeaker - White
Bose Panaray MA12 Modular Vertical Line-Array Loudspeaker - White
Wide 145° horizontal coverage. Designed to provide outstanding vocal intelligibility in acoustically demanding spaces. Slim column enclosure blends with almost any décor.
FEATURES
- Twelve 2.25" (64 mm) drivers mounted in a vertical line array deliver wide horizontal coverage with narrow vertical pattern control
- Modular design allows stacking of multiple enclosures in a line array configuration to provide increased vertical pattern control which improves “throw” distance and reduces unwanted floor/ceiling reflections
- 145° horizontal x 20° nominal coverage for a single module. Vertical coverage varies with number of modules stacked in line array configuration
- Mid/high configuration allows bass management and design flexibility. Use with Bose MB4, MB12, or MB24 modular bass loudspeakers for full-range reinforcement
- Optional brackets allow easy installation of single-, double- or triple-stack line array modules
SPECIFICATIONS
- Frequency Response (+/-3 dB) : 155 Hz - 12 kHz
- Frequency Range (-10 dB) : 100 Hz - 16 kHz
- Nominal Dispersion : 145° H x 20° V
- Long-Term Power Handling : 300 W (1200 W peak)
- Sensitivity (SPL / 1 W @ 1 m) : 88 dB SPL
- Maximum SPL @ 1 m : 113 dB SPL (119 dB SPL peak)
- Nominal Impedance : 8 Ω
FAQ
Is warranty coverage available for my product?
Yes! Majority of our product provides a minimum 1 year warranty on the electronic parts.
Can I test the product prior to my purchase?
Definitely! You can contact our sales team through 016-3111286 or head over to Music Bliss showroom to view the item before buying it. We are honored to have you over!
How long will it take to deliver?
It usually takes only 3-7 working days for the item to be safely delivered to your doorstep. Self-collection and Lalamove (local delivery) is available as well!
Can I self-collect my item(s)?
Of course! You can head over to Music Bliss showroom for self-collection during our working hours.
10am - 7.30pm (Mon - Thurs)
10am - 7pm (Fri - Sat)
10am - 6pm (Sun)
Can I use Lalamove / Grab / Same Day Delivery as a delivery option?
Yes! Please note that the delivery hour for Lalamove service is only available for local delivery, from 11am to 5pm daily. For delivery ,please check out choosing Lalamove/Grab service or contact the mainline 016-3111286.
Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
Bose Panaray MA12 Modular Vertical Line-Array Loudspeaker - White
Wide 145° horizontal coverage. Designed to provide outstanding vocal intelligibility in acoustically demanding spaces. Slim column enclosure blends with almost any décor.
FEATURES
- Twelve 2.25" (64 mm) drivers mounted in a vertical line array deliver wide horizontal coverage with narrow vertical pattern control
- Modular design allows stacking of multiple enclosures in a line array configuration to provide increased vertical pattern control which improves “throw” distance and reduces unwanted floor/ceiling reflections
- 145° horizontal x 20° nominal coverage for a single module. Vertical coverage varies with number of modules stacked in line array configuration
- Mid/high configuration allows bass management and design flexibility. Use with Bose MB4, MB12, or MB24 modular bass loudspeakers for full-range reinforcement
- Optional brackets allow easy installation of single-, double- or triple-stack line array modules
SPECIFICATIONS
- Frequency Response (+/-3 dB) : 155 Hz - 12 kHz
- Frequency Range (-10 dB) : 100 Hz - 16 kHz
- Nominal Dispersion : 145° H x 20° V
- Long-Term Power Handling : 300 W (1200 W peak)
- Sensitivity (SPL / 1 W @ 1 m) : 88 dB SPL
- Maximum SPL @ 1 m : 113 dB SPL (119 dB SPL peak)
- Nominal Impedance : 8 Ω
