Amperes AVC CU100 Main Controller for Conference System

---

It is the main controller with 4 trunks, each powering a Chairman and Delegates with a total 15 sets. It also has balanced line output for connection to external sound system and recording device. External audio source such as from PC or DVD audio ( or other audio source ) are available for feed to the delegate units.

CU100 can also be used as power extender if the number of delegates exceed the capacity of single controller. They can be stacked up to form up to 255 delegates.

---

SPECIFICATIONS

• Power supply : 220 - 240V ac : 50 / 60 Hz
• Frequency response : 100 - 12.5 kHz
• Output impedance : RCA : 200 Ohm
• Balanced      : 6.9 kOhm
  Unbalanced : 6.8 kOhm
• Input impedance : 50 kOhm
• S/N ratio : Line : 100 dB
• Dimensions : 480 x 44 x 200 mm
• Accessories : 10m 8 pair shielded

---
