AKG DGN99 E Dynamic Gooseneck Microphone

---

The DGN99 and DGN99 E are dynamic gooseneck microphones with cardioid polar pattern for general public address and communication use. The microphones provide a frequency response tailored for optimum intelligibility, good off-axis rejection for high gain before feedback and suppression of unwanted ambient noise. The all-metal body ensures a long, useful life for the microphone even in tough day-to-day use. The DGN99 E comes with an integrated XLR connector while the DGN99 offers open cables for universal use. Using a dynamic capsule, the microphones do not require any powering.

---

FEATURES

• Ideal for Paging & PA
• XLR Connector Base
• Cardioid Polar Pattern
• Tailored for Speech Pickup

---

SPECIFICATIONS

Microphone

• Capsule : Dynamic
• Polar Pattern : Cardioid

Performance

• Frequency Range : 150 Hz to 15 kHz
• Maximum SPL : 133 dB SPL (1% THD)
• Impedance : 530 Ohms
• Load Impedance : 2 Kilohms (Recommended)
• Sensitivity : 2 mV/Pa | -54 dBV
• Signal-to-Noise Ratio : 73 dB A-Weighted
• Equivalent Noise Level : 21 dB A-Weighted

Connectivity

• Output Connectors (Analog) : 1 x XLR 3-Pin

Physical

• Weight : 10 oz / 285 g

---
